National Aerospace Std - Steel Bolt, Shear | NAS6204-46

• Thread Class: 3A
• Thread Direction: Right-Hand
• Thread Length: 0.370 Inches Nominal
• Fastener Length: 3.230 Inches Minimum And 3.260 Inches Maximum
• Head Style: Dished Hexagon
• Head Height: 0.125 Inches Nominal
• Width Between Flats: 0.429 Inches Nominal
• Grip Diameter: 0.248 Inches Nominal
• Nominal Thread Diameter: 0.250 Inches
• Grip Length: 2.265 Inches Nominal
• Thread Quantity Per Inch: 28
• Minimum Tensile Strength: 160000 Pounds Per Square Inch
• Material: Steel Overall
• Surface Treatment: Cadmium Overall
• Thread Series Designator: Unjf
• Specification/Standard Data: 80205-Nas6204-46 Professional/Industrial Association Standard
